Omron SYSDRIVE 3G3RV Series User Manual

1
-
4
Differences by Model
The RV-series products differ in specifications by model. This section explains the differences.
K
KK
K Differences in Hardware
For details, refer to Chapter 3 The Digital Operator and Chapter 2 Wiring.
Note Abbreviations in the table have the following meanings.
SPDT: Single-pole Double-throw
SPST-N.O.: Single-pole Single-throw with Normally Open Contact
K
KK
K Differences in Software (Function, Factory Setting, and Setting Range)
Refer to Chapter 5 Parameters for details.
Table 1.3 Differences in Hardware
Asia
Europe
(suffixed -E)
Digital Operator
LED type attached
(LCD type is sold separately.)
LED type: 3G3IV-PJVOP161
LCD type: 3G3IV-PJVOP160
LED type attached
(LCD type is sold separately.)
LED type: 3G3IV-PJVOP161
LCD type: 3G3IV-PJVOP160
Digital outputs
Multi-function output 1
P1-PC
Transistor output
M3-M4
Relay contact output
(SPST-N.O.)
Multi-function output 2
P2-PC
Transistor output
M5-M6
Relay contact output
(SPST-N.O.)
Analog Input A1
Unsigned 10 bits
0 V to +10 V
Unsigned 12 bits
-10 V to 10 V
Control Circuit Terminal Block M3.5 screw terminal Phoenix type
Table 1.4 Differences in Software
Name Parameter Number Asia
Europe


suffixed -E


Prohibition of reverse
operation
b1-04
Setting range: 0 or 1
0: Reverse enabled
1: Reverse disabled
Setting range: 0 to2
0: Reverse enabled
1: Reverse disabled
2: Phase order changed
(Only for V/f control)
DC injection braking
time at stop
b2-04
Factory setting
0.50 s
Factory setting
0.00 s
Timer function ON/
OFF-delay time
b4-01
b4-02
Setting range
0.0 to 300.0 s
Setting range
0.0 to 3000.0 s
PID set point setting
b5-18
b5-19
Disabled Enable the PID set point setting
c
a
b
