Omron SYSDRIVE 3G3RV Series User Manual

S
YSDRIVE RV Introduction
1
-
3
Note To make IP00 Inverters satisfy the IP20 protective structure, install the Inverter into an IP20 structured box.
n400-V Class RV-series Inverter Models
Table 1.2 RV-series Inverter Models (400-V Class)
Note To make IP00 Inverters satisfy the IP20 protective structure, install the Inverter into an IP20 structured box.
Open Chassis type
IP00
22 kW 3G3RV-B2220 3G3RV-B2220-E
30 kW 3G3RV-B2300 3G3RV-B2300-E
37 kW 3G3RV-B2370 3G3RV-B2370-E
45 kW 3G3RV-B2450 3G3RV-B2450-E
55 kW 3G3RV-B2550 3G3RV-B2550-E
75 kW 3G3RV-B2750 3G3RV-B2750-E
90 kW 3G3RV-B2900 3G3RV-B2900-E
110 kW 3G3RV-B211K 3G3RV-B211K-E
Protective
Structure
Maximum Applied Motor
Capacity
Model


Asia


Model


Europe


NEMA1type
IP20
0.4 kW 3G3RV-A4004 3G3RV-A4004-E
0.75 kW 3G3RV-A4007 3G3RV-A4007-E
1.5 kW 3G3RV-A4015 3G3RV-A4015-E
2.2 kW 3G3RV-A4022 3G3RV-A4022-E
3.7 kW 3G3RV-A4037 3G3RV-A4037-E
4.0 kW Not Available 3G3RV-A4040-E
5.5 kW 3G3RV-A4055 3G3RV-A4055-E
7.5 kW 3G3RV-A4075 3G3RV-A4075-E
11 kW 3G3RV-A4110 3G3RV-A4110-E
15 kW 3G3RV-A4150 3G3RV-A4150-E
19 kW 3G3RV-A4185 3G3RV-A4185-E
22 kW
Not available
Use IP00 type
3G3RV-A4220-E
30 kW 3G3RV-A4300-E
37 kW 3G3RV-A4370-E
45 kW 3G3RV-A4450-E
55 kW 3G3RV-A4550-E
75 kW 3G3RV-A4750-E
90 kW 3G3RV-A4900-E
110 kW 3G3RV-A411K-E
132 kW 3G3RV-A413K-E
160 kW 3G3RV-A416K-E
Open Chassis
type
IP00
22 kW 3G3RV-B4220 3G3RV-B4220-E
30 kW 3G3RV-B4300 3G3RV-B4300-E
37 kW 3G3RV-B4370 3G3RV-B4370-E
45 kW 3G3RV-B4450 3G3RV-B4450-E
55 kW 3G3RV-B4550 3G3RV-B4550-E
75 kW 3G3RV-B4750 3G3RV-B4750-E
90 kW 3G3RV-B4900 3G3RV-B4900-E
110 kW 3G3RV-B411K 3G3RV-B411K-E
132 kW 3G3RV-B413K 3G3RV-B413K-E
160 kW 3G3RV-B416K 3G3RV-B416K-E
Protective
Structure
Maximum Applied Motor
Capacity
Model
(Asia)
Model
(Europe)
