Omron SYSDRIVE 3G3RV Series User Manual

2
-
20
K
KK
K Standard Connection Diagrams
Standard Inverter connection diagrams are shown in Fig 2.8. The connections depend on the Inverter capacity.
Control power is supplied internally from the main circuit DC power supply for all Inverter models.
Fig 2.8 Main Circuit Terminal Connections
n3G3RV-A2004 to A2185, A4004 to A4185
Be sure to remove the short-circuit bar before connecting the DC
reactor.
n3G3RV-B2220, B2300, B4220 to B4550
The DC reactor is built in.
n3G3RV-B2370 to B211K n3G3RV-B4750 to B416K
DC reactor
(optional)
3-phase 200
VAC (400 VAC)
Braking Resistor
Unit (optional)
Braking Unit
(optional)
Braking Resistor
Unit (optional)
3-phase 200
VAC (200 VAC)
l
3-phase
200 VAC
Braking Unit
(optional)
Braking Resistor
Unit (optional)
l
3-phase
400 VAC
Braking Unit
(optional)
Braking Resistor
Unit (optional)
