K Switching Operations between a Communications Option Card and Con-
trol Circuit Terminals
You can switch reference input between the Communications Option Card and the control circuit terminals.
Set one of the parameters H1-01 to H1-05 (multi-function input terminal S3 to S7 function selection) to 2
(Option/Inverter selection) to enable switching reference input using the terminal ON/OFF status when the
Inverter is stopped.
nSetting Precautions
To switch command inputs between the Communications Option Card and the control circuit terminals, set the
following parameters.
• Set b1-01 (Reference Selection) to 1 (Control circuit terminal [analog input])
• Set b1-02 (Operation Method Selection to 1 (Control circuit terminal (sequence inputs])
• Set one of the parameters H1-01 to H1-05 (multi-function contact input terminal S3 to S7 function selec-
tion) to 2 (Option/Inverter selection).
K
KK
K Jog Frequency Operation without Forward and Reverse Commands
(FJOG/RJOG)
The FJOG/RJOG command functions operate the Inverter using jog frequencies by using the terminal ON/
OFF operation. When using the FJOG/RJOG commands, there is no need to input the run command.
To use this function, set one of the parameters H1-01 to H1-05 (multi-function contact input terminal S3 to S7
function selection) to 12 (FJOG command) or 13 (RJOG command).
nRelated Parameters
Multi-Function Digital Inputs (H1-01 to H1-05)
Terminal Status Frequency Reference and Run Command Selection
OFF
Inverter
(Can be operated from frequency reference or control circuit terminal from analog input termi-
nal.)
ON
Communications Option Card
(Frequency reference and run command are enabled from communications Option Card.)
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD Display
d1-17
Jog frequency reference
The frequency reference when the jog frequency
reference selection, FJOG command, or RJOG
command is ON.
0 to
400.00
6.00 Hz Yes Q Q Q
Jog Reference
Set
Value
Function
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
12 FJOG command (ON: Forward run at jog frequency d1-17) Yes Yes Yes
13 RJOG command (ON: Reverse run at jog frequency d 1- 17) Yes Yes Ye s
