Omron SYSDRIVE 3G3RV Series

T
erminal Block Configuration
2
-
7
K
KK
K Terminal Arrangement for European Models
The terminal arrangement for European-model Inverters is shown in Fig 2.6 and Fig 2.7.
Fig 2.6 18.5 kW or Less
Fig 2.7 22 kW or More
Control circuit terminals
Main circuit terminals
Charge indicator
Ground terminals
Control circuit terminals
Main circuit terminals
Charge indicator
Ground terminals
