Omron SYSDRIVE 3G3RV Series User Manual

A
cceleration and Deceleration Characteristics
6
-
2
3
K
KK
K Preventing the Motor from Stalling During Acceleration (Stall Prevention
During Acceleration Function)
The Stall Prevention During Acceleration function prevents the motor from stalling if a heavy load is placed
on the motor, or sudden rapid acceleration is performed.
If you set L3-01 to 1 (enabled) and the Inverter output current exceeds the -15% level of the set value in L3-
02, the acceleration rate will begin to slow down. When L3-02 is exceeded, acceleration will stop.
If you set L3-01 to 2 (optimum adjustment), the motor current accelerates to the value set in L3-02. With this
setting, the acceleration time setting is ignored.
nRelated Parameters
*Shows the initial value when C6-01 is set to 1. If C6-01 is set to 0, the initial value is 150%.
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD Display
L3-01
Stall prevention selection
during acceleration
0: Disabled (Accelerates according to the setting.
Motor may stall if the load is too great.)
1: Enabled (Acceleration stops when the level set
in L3-02 is exceeded. Acceleration restarts
using current value recovery.)
2: Optimum adjustment (Adjusts acceleration
using the level set in L3-02 as the standard.
The acceleration time setting is ignored.)
0 to 21 NoAAA
StallP Accel Sel
L3-02
Stall prevention level dur-
ing acceleration
Set as a percent taking the Inverter rated voltage to
be 100%.
Normally, it is not necessary to change this setting.
Lower the set value if the motor stalls using the
factory setting.
0 to 200 120%* No A A A
StallP Accel Lvl
L3-03
Stall prevention limit dur-
ing acceleration
If using the motor at a frequency higher than the
setting in E1-06, set the lower limit of the stall pre-
vention level during acceleration as a percent, tak-
ing the Inverter rated current to be 100%.
Normally, it is not necessary to change this setting.
0 to 100 50% No A A A
StallP CHP Lvl
