Omron SYSDRIVE 3G3RV Series User Manual

P
arameter Tables
5
-
3
1
nField Weakening: d6
Parameters for the field weakening command are shown in the following table.
K
KK
K Motor Constant Parameters: E
The following settings are made with the motor constant parameters (E parameters): V/f characteristics and
motor constants.
nV/f Pattern: E1
Parameters for V/f characteristics are shown in the following table.
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
d6-01
Field weak-
ening level
Set the Inverter output volt-
age when the field weaken-
ing command is input.
It is enabled when the field
weakening command is set
for a multi-function input.
Set the level as a percentage
taking the voltage set in the
V/f pattern as 100%.
0 to
100
80% No A A No 2A0H -
Field-Weak
Lvl
d6-02
Field
frequency
Set the lower limit in hertz of
the frequency range where
field control is valid.
The field weakening com-
mand is valid only at fre-
quencies above this setting
and only when the speed is
in agreement with the cur-
rent speed reference.
0.0 to
400.0
0.0 Hz No A A No 2A1H -
Field-Weak
Freq
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register
Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
E1-01
Input
voltage
setting
Set the Inverter input voltage in 1
volt.
This setting is used as a reference
value in protection functions.
155 to
255
*1
200 V
*1
No Q Q Q 300H
4-7
6-129
Input
Voltage
E1-03
V/f pat-
tern selec-
tion
0 to E: Select from the 15 preset
patterns.
F: Custom user-set patterns
(Applicable for settings
E1-04 to E1-10.)
0 to F F No Q Q No 302H
6-129
V/F
Selection
