K Terminal Function Parameters: H
The following settings are made with the terminal function parameters (H parameters): Settings for external
terminal functions.
nMulti-function Digital Inputs: H1
Parameters for multi-function digital inputs are shown in the following tables.
*The values in parentheses indicate initial values when initialized in 3-wire sequence.
Multi-function Digital Input Functions
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
H1-01
Terminal S3
function
selection
Multi-function contact input
1
0 to 68 24 No A A A 400H -
Terminal S3
Sel
H1-02
Terminal S4
function
selection
Multi-function contact input
2
0 to 68 14 No A A A 401H -
Terminal S4
Sel
H1-03
Terminal S5
function
selection
Multi-function contact input
3
0 to 68
3 (0)
*
No AAA402H -
Terminal S5
Sel
H1-04
Terminal S6
function
selection
Multi-function contact input
4
0 to 68
4 (3)
*
No AAA403H -
Terminal S6
Sel
H1-05
Terminal S7
function
selection
Multi-function contact input
5
0 to 68
6 (4)
*
No AAA404H -
Terminal S7
Sel
Set-
ting
Value
Function
Control Methods
Page
V/f
V/f
with
PG
Open
Loop
Vec-
tor
03-wire sequence (Forward/Reverse Direction) Yes Yes Yes 6-13
1 Local/Remote selection (ON: Operator, OFF: Parameter setting) Yes Yes Yes 6-62
2 Option/Inverter selection (ON: Option Card) Yes Yes Yes 6-70
3
Multi-step speed reference 1
When H3-09 is set to 0, this function works as the master/auxiliary speed switch.
Yes Yes Yes 6 -10
4 Multi-step speed reference 2YesYesYes6-10
