Omron SYSDRIVE 3G3RV Series User Manual

5
-
46
5 Multi-step speed reference 3YesYesYes6-10
6Jog frequency command (higher priority than multi-step speed reference) Yes Yes Yes 6-10
7 Accel/decel time 1YesYesYes6-20
8 External baseblock NO (NO contact: Baseblock at ON) Yes Ye s Yes 6 -63
9 External baseblock NC (NC contact: Baseblock at OFF) Yes Yes Ye s 6 -63
A
Acceleration/deceleration ramp hold (ON: Acceleration/deceleration stopped, fre-
quency on hold)
Yes Yes Ye s 6 -64
B OH2 alarm signal input (ON: OH2 will be displayed) Yes Yes Yes -
C Multi-function analog input selection (ON: Enable) Yes Yes Yes -
D
No V/f control with PG (ON: Speed feedback control disabled,) (normal V/f con-
trol)
No Yes No -
ESpeed control integral reset (ON: Integral control disabled) No Yes No -
FNot used (Set when a terminal is not used) - - - -
10 Up command (Always set with the down command) Yes Yes Yes 6-65
11 Down command (Always set with the up command) Yes Yes Yes 6-65
12 FJOG command (ON: Forward run at jog frequency d1 -17) Yes Yes Ye s 6 -70
13 RJOG command (ON: Reverse run at jog frequency d1 -17) Yes Ye s Yes 6 -70
14 Fault reset (Reset when turned ON) Yes Yes Ye s 7- 2
15
Deceleration stop. (Normally open condition: Deceleration to stop in deceleration
time set in C1-09 when ON.)
Yes Yes Ye s 6 -18
16 Motor switch command (Motor 2 selection) Yes Yes Yes -
17
Deceleration stop (Normally closed condition: Deceleration to stop in deceleration
time set in C1-09 when OFF)
Yes Yes Ye s 6 -18
18
Timer function input (Functions are set in b4-01 and b4-02 and the timer function
outputs are set in H1-oo and H2-oo.)
Yes Yes Ye s
6-
116
19 PID control disable (ON: PID control disabled) Yes Yes Yes
6-
120
1A Accel/Decel time 2YesYesYes6-20
1B
Parameters write enable (ON: All parameters can be written-in. OFF: All parame-
ters other than frequency monitor are write protected.)
Yes Yes Ye s
6-141
1C
Trim control increase (ON: d4-02 frequency is added to analog frequency refer-
ence.)
Yes Yes Ye s 6 -68
1D
Trim control decrease (ON: d4-02 frequency is subtracted from analog frequency
reference.)
Yes Yes Ye s 6 -68
1E Analog frequency reference sample/hold Yes Yes Yes 6-69
20 to
2F
External fault (Desired settings possible)
Input mode: NO contact/NC contact, Detection mode: Normal/during operation
Yes Yes Ye s 6 -71
30
PID control integral reset (reset when reset command is input or when stopped dur-
ing PID control)
Yes Yes Ye s
6-
120
31 PID control integral hold (ON: Hold) Yes Yes Yes
6-
120
32 Multi-step speed command 4YesYesYes-
Set-
ting
Value
Function
Control Methods
Page
V/f
V/f
with
PG
Open
Loop
Vec-
tor
