Omron SYSDRIVE 3G3RV Series User Manual

6
-
58
K
KK
K Continuing Operation at Constant Speed When Frequency Reference Is
Lost
The frequency reference loss detection function continues operation using 80% speed of the frequency refer-
ence before loss when the frequency reference using an analog input is reduced 90% or more in 400 ms.
When the error signal during frequency reference loss is output externally, set H2-01 to H2-03 (multi-function
contact output terminal M1-M2, P1-PC/M3-M4, and P2-PC/M5-M6 function selection) to C (frequency refer-
ence lost).
nRelated Parameters
*For (-E) models only. Otherwise always 80.0%.
K
KK
K Restarting Operation After Transient Fault (Auto Restart Function)
If an Inverter error occurs during operation, the Inverter will perform self-diagnosis. If no error is detected, the
Inverter will automatically restart. This is called the auto restart function.
Set the number of auto restarts in parameter L5-01.
The auto restart function can be applied to the following faults. If an fault not listed below occurs, the protec-
tion function will operate and the auto restart function will not.
*When L2-01 is set to 1 or 2 (continue operation during momentary power loss)
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD Display
L4-05
Operation when frequency
reference is missing
0: Stopped (Operation follows frequency refer-
ence.)
1: Operation at 80% speed continues (At 80% of
speed before the frequency reference was
lost.)
Frequency reference is lost: Frequency reference
dropped over 90% in 400 ms.
0 or 10 NoAAA
Ref Loss Sel
L4-06
Frequency reference for
loss of frequency reference
Enables operation selection when frequency ref-
erence is lost and operation at the following
speed:
(Speed prior to loss) x L4-06
0.0 to
100.0%
80.0 No
A
*
A
*
A
*
Fref at Floss
•OC (Overcurrent) • RH (Braking resistor overheated)
•GF (Ground fault) • RR (Braking transistor fault)
•PUF (Fuse blown) • OL1 (Motor overload)
•OV (Main circuit overvoltage) • OL2 (Inverter overload)
• UV1 (Main Circuit Undervoltage, Main Circuit MC Operation Failure)
*
• OH1 (Motor overheat)
•PF (Main circuit voltage fault) • OL3 (Overtorque)
•LF (Output phase failure) • OL4 (Overtorque)
