Omron SYSDRIVE 3G3RV Series User Manual

2
-
6
Terminal Block Configuration
K
KK
K Terminal Arrangement for Asian Models
The terminal arrangement for Asian-model Inverters is shown in Fig 2.4 and Fig 2.5.
Fig 2.4 200-V Class Inverter for 0.4 kW
Fig 2.5 200-V class Inverter for 22 kW
Control circuit terminals
Main circuit terminals
Charge indicator
Ground terminal
E (G) FM AC AM
SC A1 A2 +V AC
P1 P2 PC
S1 S2 S3 S4
S5
S6 S7
SC
MA
M1
MB MC
M2
E (G)
MP
RP R+ R- S+ S-
IG
Control circuit terminals
Charge indicator
Main circuit terminals
Ground terminal
