Omron SYSDRIVE 3G3RV Series User Manual

D
igital Operator Functions
6
-
1
35
Digital Operator Functions
This section explains the Digital Operator functions.
K
KK
K Setting Digital Operator Functions
You can set Digital Operator-related parameters such as selecting the Digital Operator display, multi-function
selections, and copy functions.
nRelated Parameters
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD Display
o1-02
Monitor selection after
power up
Set the monitor item to be displayed when the
power supply is turned ON.
1: Frequency reference
2: Output frequency
3: Output current
4: The monitor item set for o1-01
1 to 41 YesAAA
Power-On Monitor
o1-03
Frequency units of refer-
ence setting and monitor
Sets the units that will be set and displayed for the
frequency reference and frequency monitor.
0: 0.01 Hz units
1: 0.01% (Maximum output fre-
quency is 100%)
2 to 39: r/min units (Sets the motor poles)
40 to 39999: User desired display
Set the desired values for setting
and display for the max. output
frequency.
Example: When the max. output frequency value
is 200.0, set 12000.
0 to
39999
0NoAAA
Display Scaling
o2-01
LOCAL/REMOTE key
enable/disable
Set the run method selection key (LOCAL/
REMOTE Key) function.
0: Disabled
1: Enabled (Switches between the Digital Opera-
tor and the parameter settings.)
0 or 11 NoAAA
Local/Remote Key
o2-02
STOP Key during control
circuit terminal operation
Set the STOP Key in the run mode.
0: Disabled (When the run command is issued
from an external terminal, the Stop Key is dis-
abled.)
1: Enabled (Effective even during run.)
0 or 11 NoAAA
Oper STOP Key
o2-03
Parameter initial value
When the frequency reference is set on the Digital
Operator frequency reference monitor, sets
whether the Enter key is necessary.
0: Enter Key needed
1: Enter Key not needed
2: All clear (clears all recorded user initial val-
ues)
When set to 1, the Inverter accepts the frequency
reference without Enter Key operation.
0 to 20 NoAAA
User Defaults
Set 4-digit number
excluding the decimal
point.
Set the number of digits
below the decimal point
to display.
