Omron SYSDRIVE 3G3RV Series User Manual

D
igital Operator
3
-
3
K
KK
K Digital Operator Keys
The names and functions of the Digital Operator Keys are described in Table 3.1.
Note Except in diagrams, Keys are referred to using the Key names listed in the above table.
Table 3.1 Key Functions
Key Name Function
LOCAL/REMOTE Key
Switches between operation via the Digital Operator (LOCAL) and
control circuit terminal operation (REMOTE).
This Key can be enabled or disabled by setting parameter o2-01.
MENU Key Selects menu items (modes).
ESC Key Returns to the status before the ENTER Key was pressed.
JOG Key
Enables jog operation when the Inverter is being operated from the
Digital Operator.
FWD/REV Key
Selects the rotation direction of the motor when the Inverter is being
operated from the Digital Operator.
Digit Selection/RESET Key
Sets the number of digits for parameter settings.
Also acts as the Reset Key when a fault has occurred.
Increment Key
Selects menu items, sets parameter numbers, and increments set val-
ues.
Used to move to the next item or data.
Decrement Key
Selects menu items, sets parameter numbers, and decrements set val-
ues.
Used to move to the previous item or data.
ENTER Key
Pressed to enter menu items, parameters, and set values.
Also used to switch from one screen to another.
RUN Key
Starts the Inverter operation when the Inverter is being controlled by
the Digital Operator.
STOP Key
Stops Inverter operation.
This Key can be enabled or disabled when operating from the control
circuit terminal by setting parameter o2-02.
LOCAL
REMOTE
MENU
ESC
JOG
FWD
REV
RESET
RUN
STOP
