K Option Parameters: F
The following settings are made with the option parameters (F parameters): Settings for Option Cards
nPG Option Setup: F1
Parameters for the PG Speed Control Card are shown in the following table.
* Factory setting for (-E) models is 1024.
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
F1-01
PG constant
Sets the number of PG (pulse
generator or encoder) pulses.
Sets the number of pulses
per motor revolution.
0 to
60000
600
(1024)
*
No No Q No 380H 6-143
PG Pulses/
Rev
F1-02
Operation
selection at
PG open
circuit
(PGO)
Sets the PG disconnection
stopping method.
0: Ramp to stop
(Deceleration stop using
Deceleration Time 1, C1-
02.)
1: Coast to stop
2: Fast stop (Emergency
stop using the
deceleration time in C1-
09.)
3: Continue operation (To
protect the motor or
machinery, do not
normally make this
setting.)
0 to 3 1 No No A No 381H 6-143
PG Fdbk
Loss Sel
F1-03
Operation
selection at
overspeed
(OS)
Sets the stopping method
when an overspeed (OS)
fault occurs.
0: Ramp to stop
(Deceleration stop using
Deceleration Time 1, C1-
02.)
1: Coast to stop
2: Fast stop (Emergency
stop using the
deceleration time in C1-
09.)
3: Continue operation (To
protect the motor or
machinery, do not
normally make this
setting.)
0 to 3 1 No No A No 382H 6-143
PG Over-
speed Sel
