Omron SYSDRIVE 3G3RV Series User Manual

P
arameter Tables
5
-
3
9
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
F1-04
Operation
selection at
deviation
Sets the stopping method
when a speed deviation
(DEV) fault occurs.
0:Ramp to stop
(Deceleration stop using
Deceleration Time 1, C1-
02.)
1:Coast to stop
2:Fast stop (Emergency
stop using the
deceleration time in C1-
09.)
3:Continue operation (DEV
is displayed and
operation continued.)
0 to 3 3 No No A No 383H 6-143
PG Devia-
tion Sel
F1-05
PG rotation
0:Phase A leads with
forward run command.
(Phase B leads with
reverse run command.)
1:Phase B leads with
forward run command.
(Phase A leads with
reverse run command.)
0 or 1 0 No No A No 384H 6-143
PG Rota-
tion Sel
F1-06
PG division
rate (PG
pulse moni-
tor)
Sets the division ratio for the
PG Speed Control Card
pulse output.
Division ratio = (1+ n) /m
(n=0 or 1 m=1 to 32)
This parameter is only effec-
tive when a PG-B2 is used.
The possible division ratio
settings are: 1/32 ≤ F1-06 ≤
1.
1 to
132
1 No No A No 385H 6-144
PG Output
Ratio
F1-07
Integral
value during
accel/decel
enable/dis-
able
Sets integral control during
acceleration/deceleration to
either enabled or disabled.
0:Disabled (The integral
function isn't used while
accelerating or
decelerating; it is used at
constant speeds.)
1:Enabled (The integral
function is used at all
times.)
0 or 1 0 No No A No 386H 6-144
PG Ramp
PI/I Sel
F1-06
nm
