28
n Output Noise Filter
An
Output
Noise
Filter
controls
noise
generated
by
the
Inverter
so
it
does
not
enter
the
power
supply.
It
is
con-
nected
to
the
motor
output
side.
Models and Application
The
standard
models
of
Output
Noise
Filters
are
listed
in
the
following
table.
Connect
the
Filters
in
parallel
when
connecting
more
than
one
Filter,
and
use
a
relay
terminal
block
to
balance
the
current.
Inverter Output Noise Filter
Voltage
Class
Max. Applicable
Motor Capacity
(kW)
Inverter
Capacity
(kVA)
No. Qty
Rated
Current
(A)
200-V
Class
0.4 1.2 3G3IV-PLF310KA 1 10
0.75 1.6 3G3IV-PLF310KA 1 10
1.5 2.7 3G3IV-PLF310KA 1 10
2.2 3.7 3G3IV-PLF310KA 1 10
3.7 5.7 3G3IV-PLF320KA 1 20
5.5 8.8 3G3IV-PLF350KA 1 50
7.5 12 3G3IV-PLF350KA 1 50
11 17 3G3IV-PLF350KA 2 100
15 22 3G3IV-PLF350KA 2 100
18.5 27 3G3IV-PLF350KA 2 100
22 32 3G3IV-PLF350KA 3 150
30 44 3G3IV-PLF350KA 3 150
37 55 3G3IV-PLF3110KB 2 220
45 69 3G3IV-PLF3110KB 2 220
55 82 3G3IV-PLF3110KB 3 330
75 110 3G3IV-PLF3110KB 4 440
90 130 3G3IV-PLF3110KB 4 440
110 160 3G3IV-PLF3110KB 5 550
400-V
Class
0.4 1.4 3G3IV-PLF310KB 1 10
0.75 1.6 3G3IV-PLF310KB 1 10
1.5 2.8 3G3IV-PLF310KB 1 10
2.2 4 3G3IV-PLF310KB 1 10
3.7 5.8 3G3IV-PLF310KB 1 10
5.5 9.5 3G3IV-PLF320KB 1 20
7.5 13 3G3IV-PLF320KB 1 20
11 18 3G3IV-PLF335KB 1 35
15 24 3G3IV-PLF335KB 1 35
18.5 30 3G3IV-PLF345KB 1 45
22 34 3G3IV-PLF375KB 1 75
30 46 3G3IV-PLF375KB 1 75
37 57 3G3IV-PLF3110KB 1 110
45 69 3G3IV-PLF3110KB 1 110
55 85 3G3IV-PLF375KB 2 150
75 110 3G3IV-PLF3110KB 2 220
90 140 3G3IV-PLF3110KB 3 330
110 160 3G3IV-PLF3110KB 3 330
132 200 3G3IV-PLF3110KB 4 440
160 230 3G3IV-PLF3110KB 4 440
