K Common Specifications
The following specifications apply to both 200 V and 400 V Class Inverters.
Note Rotational autotuning is required to obtain the specifications labeled as open loop vector control.
*1.Not including the 200 V Class Inverter for 110 kW and the 400 V Class Inverters for 220 and 300 kW.
* 2. Increase the Inverter capacity if loads exceeding these current values are expected.
Table 9.3 Common Specifications
Model Number
3G3RV-o
oo
o
Specification
Control method
Sine wave PWM
Open loop vector control, V/f control, V/f with PG control (switched by parameter setting)
Speed control range 1:100 (Open loop vector control)
Speed control accuracy ±0.2% (25°C ± 10°C) (Open loop vector control)
Speed control response 5 Hz (Open loop vector control)
Tor que characteristics
CT selected (low carrier, fixed torque applications): 150% /0.5 Hz
VT selected (high carrier, variable torque applications): 120%/0.5 Hz (Open loop vector control)
Tor que limits Can be set using parameter settings for open loop vector control only.
Frequency control range 0.01 to 150 Hz (CT selected.), 0.01 to 400 Hz (VT selected.)
Frequency accuracy (tem-
perature characteristics)
Digital references: ± 0.01% (-10°C to +40°C)
Analog references: ±0.1% (25°C ±10°C)
Frequency setting resolu-
tion
Digital references: 0.01 Hz
Analog references: 0.06 Hz/60 Hz (10 bit with no sign)
Output frequency resolu-
tion
0.001 Hz
Overload capacity and
maximum current
*2
CT selected: 150% of rated output current per minute
*1
VT selected: 120% of rated output current per minute
Frequency setting signal Voltage input of 0 to ±10 or 0 to 10 (20 kΩ) VDC or current input of 4 to 20 mA
Acceleration/Decelera-
tion time
0.01 to 6000.0 s (4 selectable combinations of independent acceleration and deceleration settings)
Braking torque Approximately 20% (Approximately 125% with Braking Resistor option
Main control functions
Restarting for momentary power loss, speed searches, overtorque detection, torque limits, 16-speed control (maximum), accelera-
tion/deceleration time changes, S-curve acceleration/deceleration, 3-wire sequence, autotuning (rotational or stationary), dwell
functions, cooling fan ON/OFF control, slip compensation, torque compensation, jump frequencies, upper and lower limits for
frequency references, DC braking for starting and stopping, high-slip braking, PID control (with sleep function), energy-saving
control, RS-485/422A communications (Conforms to MODBUS,19.2 kbps maximum), fault reset, and function copying.
Motor protection Protection by electronic thermal overload relay.
Instantaneous overcurrent
protection
Stops at approx. 200% of rated output current.
Overload protection
CT selected (low carrier, fixed torque applications): 150% of rated output current per minute (except for 110 kW Inverters)
VT selected (high carrier, variable torque applications): 120% of rated output current per minute
Overvoltage protection
200 Class Inverter: Stops when main-circuit DC voltage is above 410 V.
400 Class Inverter: Stops when main-circuit DC voltage is above 820 V.
Undervoltage protection
200 Class Inverter: Stops when main-circuit DC voltage is below 190 V.
400 Class Inverter: Stops when main-circuit DC voltage is below 380 V.
Momentary power loss
ridethru
Stops for 15 ms or more.
By selecting the momentary power loss method, operation can be continued if power is restored within 2 s.
Cooling fin overheating Protection by thermistor.
Grounding protection Protection by electronic circuits. (Overcurrent level)
Charge indicator Lit when the main circuit DC voltage is approx. 50 V or more.
Application site Indoor (no corrosive gas, dust, etc.)
Ambient operating tem-
perature
-10°C to 40°C (Closed wall-mounted type)
10°C to 45°C (Open chassis type)
Ambient operating humid-
ity
95% max. (with no condensation)
Storage temperature - 20°C to + 60°C (short-term temperature during transportation)
Altitude 1000 m max.
Insulation resistance 5 MW max. (Do not perform insulation resistance with withstand voltage tests.)
Vibration
10 to 20 Hz, 9.8 m/s
2
max.; 20 to 50 Hz, 2 m/s
2
max, oscillation vibration of 20 Hz
Protective structure
Enclose, wall-mounting (NEMA1: Equivalent to IP20) or Mounted in a panel (equivalent to IP00)
Mounted in a panel (equivalent to IP00)
