Omron SYSDRIVE 3G3RV Series

M
odes
3
-
5
Modes
This section describes the Inverter's modes and switching between modes.
K
KK
K Inverter Modes
The Inverter's parameters and monitoring functions are organized in groups called modes that make it easier to
read and set parameters.The Inverter is equipped with 5 modes.
The 5 modes and their primary functions are shown in the Table 3.2.
*Always perform autotuning with the motor before operating using vector control. Autotuning Mode will not be displayed during operation or when an
error has occurred.
Table 3.2 Modes
Mode Primary function(s)
Drive Mode
The Inverter can be run in this mode.
Use this mode when monitoring values such as frequency references or output cur-
rent, displaying fault information, or displaying the fault history.
Quick Programming Mode
Use this mode to reference and set the minimum parameters to operate the Inverter
(e.g., the operating environment of the Inverter and Digital Operator).
Advanced Programming Mode Use this mode to reference and set all parameters.
Verify Mode
Use this mode to read/set parameters that have been changed from their factory-set
values.
Autotuning Mode*
Use this mode when running a motor with unknown motor constants in the vector
control mode. The motor constants are calculated and set automatically.
This mode can also be used to measure only the motor line-to-line resistance.
