Omron SYSDRIVE 3G3RV Series User Manual

W
iring Control Circuit Terminals for Asian Models
2
-
3
1
K
KK
K Control Circuit Terminal Connections
Connections to Inverter control circuit terminals are shown in Fig 2.23.
Fig 2.23 Control Circuit Terminal Connections (Asian Models)
F
ault contact output
2
50 VAC, 1 A max.
3
0 VDC, 1 A max.
Multi-function transistor 
outputs (open-collector)*
2
48 VAC, 50 mA
Default:
Frequency
agree signal
Default: Zero
speed
Multi-function output
2
50 VAC, 1 A max.
3
0 VDC, 1 A max.
Default: Running signal
4
to 20 mA
0
to 10 V
P
ulse train input
Master speed
pulse train
0 to 32 kHz (3 kΩ)
High level: 3.5 to 13.2 V
input
Frequency setting power
+15 V 20 mA
Master speed reference
0 to 10 V (20 kΩ)
M
aster speed reference
4 to 20 mA (250 W)
[0 to 10 V (20 kΩ) input]
Frequency setting
adjustment
Frequency
setter
External
frequency
references*
3
RS-485/422 
communications
Terminating
resistance
Pulse train output
0
to 32 kHz (2.2 kΩ)
Default: Output frequency
Multi-step speed
setting 1
Multi-step speed
setting 2
Jog frequency selection
Shield terminal
F
orward Run/Stop
R
everse Run/Stop
E
xternal fault
F
ault reset
CN5 (NPN setting)
Multi-function
inputs*
1
Defaults
Multi-function analog output 1
-
10 to 10 V 2 mA
Default: Output frequency
0 to +10 V
Default: Output current
0 to +10 V
-
10 to 10 V 2 mA
Multi-function analog output 2
A
mmeter adjustment
A
mmeter adjustment
Multi-function output 1
Multi-function output 2
