Omron SYSDRIVE 3G3RV Series

1
-
2
SYSDRIVE RV Introduction
K
KK
K SYSDRIVE RV Applications
The SYSDRIVE RV is ideal for the following applications.
• Fan, blower, and pump applications
• Conveyors, pushers, metal tooling machines, etc.
Settings must be adjusted to the application for optimum operation. Refer to Chapter 4 Trial Operation.
K
KK
K RV-series Inverter Models
RV-series Inverters have different models and specifications by the area (Asia and Europe) to support widely
used applications and different power supply situations in each area.
Be sure to confirm the models and the specifications you are going to purchase in RV-series Inverter Models
and Differences by Model, below.
In each area, only the products for the area are available (e.g., in Europe, only the models with “-E” are sold).
RV-series Inverters have two types of voltage class: 200-V class and the 400-V class. The capacity range of
applicable motors is 0.4 kW to 160 kW. All the models comply with EC Directives.
n200-V Class RV-series Inverter Models
Table 1.1 RV-series Inverter Models (200-V Class)
Protective
Structure
Maximum Applied Motor
Capacity
Model
(Asia)
Model
(Europe)
NEMA 1 type
IP20
0.4 kW 3G3RV-A2004 3G3RV-A2004-E
0.75 kW 3G3RV-A2007 3G3RV-A2007-E
1.5 kW 3G3RV-A2015 3G3RV-A2015-E
2.2 kW 3G3RV-A2022 3G3RV-A2022-E
3.7 kW 3G3RV-A2037 3G3RV-A2037-E
5.5 kW 3G3RV-A2055 3G3RV-A2055-E
7.5 kW 3G3RV-A2075 3G3RV-A2075-E
11 kW 3G3RV-A2110 3G3RV-A2110-E
15 kW 3G3RV-A2150 3G3RV-A2150-E
18.5 kW 3G3RV-A2185 3G3RV-A2185-E
22 kW
Not available
Use IP00 type
3G3RV-A2220-E
30 kW 3G3RV-A2300-E
37 kW 3G3RV-A2370-E
45 kW 3G3RV-A2450-E
55 kW 3G3RV-A2550-E
75 kW 3G3RV-A2750-E
90 kW
Not available
Use IP00 type
110 kW
