Removing/Attaching
the
Digital
Operator
and
Front
Cover
The
methods
for
removing
and
attaching
the
Digital
Operator
and
front
cover
are
described
in
this
section.
K
KK
K Inverters
of
18.5
kW
or
Less
To
attach
optional
cards
or
change
the
terminal
card
connector,
remove
the
Digital
Operator
and
front
cover
in
addition
to
the
terminal
cover.
Always
remove
the
Digital
Operator
from
the
front
cover
before
removing
the
terminal
cover.
The
removal
and
attachment
procedures
are
given
below.
nRemoving
the
Digital
Operator
Press
the
lever
on
the
side
of
the
Digital
Operator
in
the
direction
of
arrow
1
to
unlock
the
Digital
Operator,
and
lift
the
Digital
Operator
in
the
direction
of
arrow
2
to
remove
it
as
shown
in
the
following
illustration.
Fig
1.15
Removing
the
Digital
Operator
(3G3RV-A4055
Shown
Above)
2
1
