1
-
20
nRemoving
the
Front
Cover
Press
the
left
and
right
sides
of
the
front
cover
in
the
directions
of
arrows
1
and
lift
the
bottom
of
the
cover
in
the
direction
of
arrow
2
to
remove
the
front
cover
as
shown
in
the
following
illustration.
Fig
1.16
Removing
the
Front
Cover
(3G3RV-A4055
Shown
Above)
nMounting
the
Front
Cover
After
wiring
the
terminals,
mount
the
front
cover
to
the
Inverter
by
performing
in
reverse
order
the
steps
to
remove
the
front
cover.
1. Do
not
mount
the
front
cover
with
the
Digital
Operator
attached
to
the
front
cover;
otherwise,
the
Digital
Operator
may
malfunction
due
to
imperfect
contact.
2. Insert
the
tab
of
the
upper
part
of
the
front
cover
into
the
groove
of
the
Inverter
and
press
the
lower
part
of
the
front
cover
onto
the
Inverter
until
the
front
cover
snaps
shut.
nMounting
the
Digital
Operator
After
attaching
the
terminal
cover,
mount
the
Digital
Operator
onto
the
Inverter
using
the
following
procedure.
1. Hook
the
Digital
Operator
at
A
(two
locations)
on
the
front
cover
in
the
direction
of
arrow
1
as
shown
in
the
following
illustration.
2. Press
the
Digital
Operator
in
the
direction
of
arrow
2
until
it
snaps
in
place
at
B
(two
locations).
Fig
1.17
Mounting
the
Digital
Operator
A
B
1
2
