K Parameters Settable in Quick Programming Mode
The minimum parameters required for Inverter operation can be monitored and set in quick programming
mode. The parameters displayed in quick programming mode are listed in the following table. These, and all
other parameters, are also displayed in advanced programming mode.
Refer to the overview of modes on page 3-5 for an overview of quick programming mode.
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Regis-
ter
LCD
Display
V/f
V/f
with
PG
Open
Loop
Vec-
tor
A1-02
Control
method
selection
Set the control method for the
Inverter.
0: V/f control
1: V/f control with PG
(Pulse generator as encoder)
2: Open-loop vector control
0 to 2 0 No Q Q Q 102H
Control
Method
b1-01
Reference
selection
Set the frequency reference input
method.
0: Digital Operator
1: Control circuit terminal (analog
input)
2: RS-422A/485 communications
3: Option Card
4: Pulse train input
0 to 4 1 No Q Q Q 180H
Reference
Source
b1-02
Operation
method
selection
Set the run command input method
0: Digital Operator
1: Control circuit terminal (sequence
input)
2: RS-422A/485 communications
3: Option Card
0 to 3 1 No Q Q Q 181H
Run Source
b1-03
Stopping
method
selection
Set the stopping method when a stop
command is input.
0: Deceleration to stop
1: Coast to stop
2: DC braking stop (Stops faster than
coast to stop, without regenerative
operation.)
3: Coast to stop with timer (Run
commands are disregarded during
deceleration time.)
0 to 3 0 No Q Q Q 182H
Stopping
Method
