Omron SYSDRIVE 3G3RV Series User Manual

D
igital Operator Display Functions and Levels
5
-
5
C1-01
Accelera-
tion time 1
Set the acceleration time in seconds
for the output frequency to climb from
0% to 100%.
0.0 to
6000.0
*1
10.0 s
Yes Q Q Q 200H
Accel Time
1
C1-02
Decelera-
tion time 1
Set the deceleration time in seconds
for the output frequency to fall from
100% to 0%.
Yes Q Q Q 201H
Decel Time
1
C6-01
CT/VT
selection
0: CT (low carrier, constant torque,
150% per minute)
1: VT (high carrier, variable torque,
120% per minute)
0 or 1 1 No Q Q Q 223H
Heavy/Nor-
mal Duty
C6-02
Carrier fre-
quency
selection
Select carrier wave fixed pattern.
Select F to enable detailed settings
using parameters C6-03 to C6-07.
0 to F
6
*2
No Q Q Q 224H
CarrierFreq
Sel
d1-01
Frequency
reference 1
Set the frequency reference in the unit
specified in o1-03 (Frequency Units
for Reference Setting And Monitor,
default: Hz)
0 to
400.00
0.00
Hz
Yes Q Q Q 280H
Reference 1
d1-02
Frequency
reference 2
Frequency reference when multi-step
speed command 1 is ON for a multi-
function input (unit: Set in o1-03).
0.00
Hz
Yes Q Q Q 281H
Reference 2
d1-03
Frequency
reference 3
Frequency reference when multi-step
speed command 2 is ON for a multi-
function input (unit: Set in o1-03).
0.00
Hz
Yes Q Q Q 282H
Reference 3
d1-04
Frequency
reference 4
Frequency reference when multi-step
speed command 1 and 2 are ON for a
multi-function input (unit: Set in o1-
03).
0.00
Hz
Yes Q Q Q 283H
Reference 4
d1-17
Jog
frequency
reference
Frequency reference when Jog Fre-
quency Selection, FJOG command, or
RJOG command is ON for a multi-
function input (unit: Set in o1-03).
6.00
Hz
Yes Q Q Q 292H
Jog
Reference
E1-01
Input volt-
age setting
Set the Inverter input voltage in 1 volt.
This set value will be the basis for the
protection functions.
155 to
255
*3
200 V
*3
No Q Q Q 300H
Input Volt-
age
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Regis-
ter
LCD
Display
V/f
V/f
with
PG
Open
Loop
Vec-
tor
