92
MSB
will
be
1.
400.0
(Hz)/0.01
(Hz)
=
40000
=
9C40
Hex
Set
All
Unused
Bits
to
0
Bits
11
through
15
of
the
RUN
command
(register
0001H)
are
not
used.
When
writing
the
data,
be
sure
to
set
all
of
these
bits
to
0.
These
bits
when
read
are
set
to
0.
No
Data
Settings
in
Unused
Registers
Registers
described
“not
used”
may
be
used
for
internal
processing.
Do
not
write
any
data
to
such
registers.
Communications
with
a
Programmable
Controller
The
RS-422A/485
communications
of
the
3G3RV
Inverter
conform
to
the
MODBUS
Communications
Proto-
col.
This
protocol
cannot
share
the
same
line
with
any
other
communications
protocol.
To
control
the
3G3RV
through
RS-422A/485
communications
with
the
Programmable
Controller,
mount
a
Serial
Communications
Board
or
Unit
to
the
Programmable
Controller
and
use
the
protocol
macro
function.
The
following
settings
and
operations
are
necessary
for
serial
communications
using
the
protocol
macro
func-
tion.
• Configure
system
settings
for
the
Serial
Communications
Board
or
Unit
• Create
Send
&
Recv
procedures
conforming
to
the
MODBUS
Communications
Protocol
by
means
of
pro-
tocol
macro
tools
(CX-Protocol
or
Protocol
Support
Tool),
and
transfer
them
to
the
Serial
Communications
Board.
• Execute
the
PMCR
instruction
on
the
CPU
Unit
of
the
Programmable
Controller.
n
Applicable
Programmable
Controllers
and
Peripheral
Devices
A
Serial
Communications
Board
or
Unit
can
be
mounted
to
the
following
SYSMAC
CPU
Units.
Table 6.2 Applicable Programmable Controllers
Series CPU
Unit
models
SYSMAC
CS
High-speed
models:
CS1H-CPU67-E/66-E/65-E/64-E/63-E
Low-speed
models:
CS1G-CPU45-E/44-E/43-E/42-E
SYSMAC
CJ CJ1G-CPU44/45
SYSMAC
C200HX/HG/HE
C200HX-CPU34-E/44-E/54-E/64-E/34-ZE/44-ZE/54-ZE/64-ZE/65-ZE/85-ZE
C200HG-CPU33-E/43-E/53-E/63-E/33-ZE/43-ZE/53-ZE/63-ZE
C200HE-CPU32-E/42-E/32-ZE/42-ZE
SYSMAC
CQM1H CQM1H-CPU61/51
