C
ommunications Functions
6
-
9
3
n Applicable Serial Communications Boards and Unit
The following Serial Communications Boards and Unit can be used with the RS-422A/485 port.
The RS-232C port can be used if an RS-422/485 Conversion Adapter is installed. For ease of wiring, however,
it is recommended that the RS-422/485 port be used. The following information is for the RS-422/485 port.
nPeripheral Devices
The following peripheral devices are required to use the protocol macro function.
Table 6.3 Applicable Serial Communications Boards
Series Serial Communications Board/Unit Mounting method Specifications
SYSMAC CS CS1W-SCB41
As an Inner Board of
the CPU Unit
• One RS-232C port
• One RS-422A/485 port
• Protocol macro function
SYSMAC CJ CJ1W-SCU41 CPU Bus Unit
• One RS-232C port
• One RS-422A/485 port
• Protocol macro function
SYSMAC
C200HX/HG/HE
C200HW-COM06-EV1
Make sure that the model number has the suffix
“EV1,” otherwise the CRC-16 check code can-
not be used.
Mounted to an
optional slot of the
CPU Unit
• One RS-232C port
• One RS-422A/485 port
• Protocol macro function
SYSMAC
CQM1H
CQM1H-CPU61/51-E
As an Inner Board of
the CPU Unit
• One RS-232C port
• One RS-422A/485 port
• Protocol macro function
Table 6.4 Peripheral Devices
Name Model Specification
CX-Protocol WS02-PSTC1-E
The following peripheral devices support the protocol macro function of the
entire SYSMAC series.
Personal computer environment
Personal com-
puter
IBM PC/AT or compatible computer
CPU
Minimum requirement: Pentium 90 MHz
Recommended: Pentium 166 MHz or faster
OS Microsoft Windows 95 or Windows 98
Memory
Minimum: 16 MB
Recommended: 24 MB min.
Hard disk
Minimum: Available space of 24 MB
Recommended: Available space of 50 MB
Monitor SVGA or better
Drive
FDD: 1 or more
CD-ROM drive: 1 or more
