nManuals for Related Equipment and the Support Tool
The following manuals provide details on equipment and the Protocol Support Tool.
nSerial Communications Board/Unit SystemSettings
The system settings for the Serial Communications Board and Unit are given below.
For the CS/CJ series:
Use the following ports for the CS/CJ series.
• CS1W-SCB41 Serial Communications Board: Port 2
• CJ1W-SCU41 Serial Communications Unit: Port 2
Protocol Sup-
port Tool
WS01-PSTF1-E
The following peripheral devices support the protocol macro function of the
SYSMAC C200HX/HG/HE series.
Personal computer environment
Personal com-
puter
IBM PC/AT or compatible computer
CPU
Minimum requirement: Pentium 90 MHz
Recommended: Pentium 166 MHz or faster
OS Microsoft Windows 95 or Windows 98
Memory
Minimum: 16 MB
Recommended: 24 MB min.
Hard disk
Minimum: Available space of 24 MB
Recommended: Available space of 50 MB
Monitor SVGA or better
Drive
FDD: 1 or more
CD-ROM drive: 1 or more
Table 6.5 List of manuals
Name, series, model Cat. No.
SYSMAC CS series, CPU Unit
W339 Users Manual
W340 Instruction Reference Manual
W394 Programming Manual
SYSMAC CJ series, CPU Unit
W393 Operation Manual
W340 Instruction Reference Manual
W394 Programming Manual
SYSMAC C200HX/HG/HE
, CPU Unit
W302 Installation Guide
W303 Operation Manual
SYSMAC CQM1H CPU Unit
W363 Operation Manual
W364 Programming Manual
Serial Communications Board, CS1W-SCB21/41
Serial Communications Unit, CS1W-SCU21
Serial Communications Unit, CS1W-SCU41
W336 Users Manual
Serial Communications Board, C200HW-COM06-V1 W304 Operation Manual
Serial Communications Board, CQM1H-SCB41 W365 Operation Manual
CX-Protocol, WS02-PSTC1-E W344 Operation Manual
Protocol Support Tool WS01-PSTF1-E W319 Operation Manual
Table 6.4 Peripheral Devices
Name Model Specification
