m = D30000 + 100 x Unit No. (Wd)
*Set to this value.
For the SYSMAC C200HX/HG/HE and CQM1H Series:
Use the following ports for the SYSMAC C200HX/HG/HE and CQM1H series.
• C200HW-COM06-V1 Communications Board: Port A
• CQM1H-SCB41 Serial Communications Board: Port 2
DM Area
Bit Setting ValueBoard Unit
Port 1 Port 2 Port 1 Port 2
D32000 D32010 m m+10
15 Port setting -- 0: Default, 1*: Desired setting

14 to 12 Reserved
11 to 08
Serial communications mode
(6 Hex*: Protocol macro)
07 to 05 Reserved
04
Start bit -- 0*: 1 bit, 1: 1 bit (fixed at 1 bit regardless of
the setting)
03 Data length -- 0: 7 bits, 1*: 8 bits
02 Stop bit -- 0: 2 bits, 1*: 1 bit
01 Parity -- 0: With, 1*: Without
00 Parity -- 0*: Even, 1: Odd
D32001 D32011 m+1 m+11
15 to 04 Reserved

03 to 00
Transmission rate (unit: bps)
0: Default (9,600), 3: 1,200, 4: 2,400, 5: 4,800,
6*: 9,600, 7: 19,200, 8: 38,400
----

D32008 D32018 m+8 m+18
15
Transmission method -- 0: Half-duplex, 1*: Full-
duplex

14 to 00 Reserved
D32009 D32019 m+9 m+19 15 to 00
Max. number of bytes in send/receive data -- 00C8* to
03E8 Hex

Communications
Board
Bit Setting Value
Port 1
Port A
Port 2
Port B
DM6555 DM6550
00 to 03
Standard format setting
0 Hex: Standard setting (default)
1 Hex
*
: Settings in bits 00 to 15 of DM6656 and DM 6551 are used.
6001
04 to 11 00: Default
12 to 15
Serial Communications Board
0 Hex: Host link (default)
1 Hex: Not protocol
2 Hex: 1:1 Link slave
3 Hex: 1:1 Link master
4 Hex: NT link (1:1 mode)
5 Hex: Hex: NT link (1:N mode)
6 Hex
*
: Protocol macro
