C
onfirmations upon Delivery
1
-
7
Confirmations upon Delivery
K
KK
K Checks
Check the following items as soon as the Inverter is delivered.
If you find any irregularities in the above items, contact the dealer from which you purchased the Inverter or
your OMRON representative immediately.
K
KK
K Nameplate Information
There is a nameplate attached to the side of each Inverter. The nameplate shows the model number, specifica-
tions, lot number, serial number, and other information on the Inverter.
n Example Nameplate
The following nameplate is an example for an Asian-model Inverter: 3-phase, 200 VAC, 37 kW, IEC IP00
standards.
Fig 1.1 Nameplate
Table 1.5 Checks
Item Method
Has the correct model of Inverter been
delivered?
Check the model number on the nameplate on the side of the Inverter.
Is the Inverter damaged in any way?
Inspect the entire exterior of the Inverter to see if there are any scratches or
other damage resulting from shipping.
Are any screws or other components
loose?
Use a screwdriver or other tools to check for tightness.
3G3RV B2370
INPUT
OUTPUT
LOT NO
SER NO
AC3PH 200 220V 50Hz
AC3PH 200
230V 60Hz
AC3PH 0
230V 0 400Hz
160A
145A 55kVA
MASS
57kg
PRG
OMRON
OMRON
Corporation
MADE IN JAPAN
M
S
Inverter model
Output specifications
Lot number
Serial number
Input specifications
Mass
