Omron SYSDRIVE 3G3RV Series User Manual

5
-
2
Parameter Descriptions
This section describes the contents of the parameter tables.
K
KK
K Description of Parameter Tables
Parameter tables are structured as shown below. Here, b1-01 (Frequency Reference Selection) is used as an
example.
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
Vec-
tor
b1-01
Reference
selection
Set the frequency reference
input method.
0: Digital Operator
1: Control circuit terminal
(analog input)
2: RS-422A/485 communi-
cations
3: Option Card
4: Pulse train input
0 to 4 1 No Q Q Q 180H -
Reference
Source
• Parameter Number: The number of the parameter.
• Name: The name of the parameter.
• LCD Display: The name of the parameter displayed on the LCD-type Digital Opera-
tor.
• Description: Details on the function or settings of the parameter.
• Setting Range: The setting range for the parameter.
• Factory Setting: The factory setting (each control method has its own factory setting.
Therefore the factory setting changes when the control method is
changed.)
Refer to page 5-83 for factory settings by control method.
• Change during Operation: Indicates whether or not the parameter can be changed while the
Inverter is in operation.
Yes: Changes possible during operation.
No: Changes not possible during operation.
• Control Methods: Indicates the control methods in which the parameter can be moni-
tored or set.
Q: Items which can be monitored and set in either quick program-
ming mode or advanced programming mode.
A: Items which can be monitored and set only in advanced pro-
gramming mode.
No: Items which cannot be monitored or set for the control method.
• Register: The register number used for RS-422A/485 communications.
• Page: Reference page for more detailed information on the parameter.
