nSelecting Analog Monitor Items
The digital operator monitor items (U1-oo [status monitor]) are output from multi-function analog output
terminals FM-AC and AM-AC. Refer to Chapter 5 Parameters, and set the values for the
oo part of U1-oo
(status monitor).
Alternatively, you can output monitor items (U1-
oo [status monitor]) from analog output option terminal
channels 1 and 2 on analog monitor cards AO-08 and AO-12. Refer to the table of parameters, and set the val-
ues.
nAdjusting the Analog Monitor Items
Adjust the output voltage for multi-function analog output terminals FM-AC and AM-AC using the gain and
bias in H4-02, H4-03, H4-05, and H4-06. Also, adjust the output voltage for output channels 1 and 2 of Ana-
log Output Option Cards AO-08 and AO-12 using the gain and bias in F4-02, F4-04, and F4-06.
Adjusting the Meter
Display the data setting display for the gain and bias constants corresponding to the output channel of the
Inverter Unit and the AO Option Card while the Inverter is stopped to output the following voltages to the ana-
log monitor terminal, to enable meter adjusting while the Inverter is stopped.
F4-01
Channel 1 monitor selec-
tion
Effective when the Analog Monitor Card is used.
Monitor selection:
Set the number of the monitor item to be output.
(U1-oo)
Gain:
Set the multiple of 10 V for outputting monitor
items.
4, 10 to 14, 28, 34, 39, 40 cannot be set. 17, 23, 25,
29, 30, 31, 35 are not used.
When the AO-12 Analog Monitor Card is used,
outputs of ±10 V are possible. To output ±10 V, set
F4-07 or F4-08 to 1. When the AO-08 Analog
Monior Card is used, only outputs of 0 to +10 V
are possible.
A meter calibration function is available.
1 to 40 2 No
A
*2
A
*2
A
*2
AO Ch1 Select
F4-02
Channel 1 gain
0.00 to
2.50
1.00 Yes
A
*2
A
*2
A
*2
AO Ch1 Gain
F4-03
Channel 2 monitor selec-
tion
1 to 40 3No
A
*2
A
*2
A
*2
AO Ch2 Select
F4-04
Channel 2 gain
0.00 to
2.50
0.50 Yes
A
*2
A
*2
A
*2
AO Ch2 Gain
F4-05
Channel 1 output monitor
bias
Set the channel 1 item bias to 100%/10 V when
the analog monitor card is used.
-10.0 to
10.0
0.0 Yes
A
*2
A
*2
A
*2
AO Ch1 Bias
F4-06
Channel 2 output monitor
bias
Set the channel 2 item bias to 100%/10 V when
the analog monitor card is used.
-10.0 to
10.0
0.0 Yes
A
*2
A
*2
A
*2
AO Ch2 Bias
F4-08
Analog output signal level
for channel 2
0: 0 to 10 V
1: -10 to 10 V
0 or 10 No
A
*2
A
*2
A
*2
AO Opt Level Ch1
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD Display
