86
Note Attach
a
Momentary
Power
Interruption
Compensation
Unit
if
compensation
for
power
interruptions
of
up
to
2.0
seconds
is
required
for
200-V
class
Inverters
with
outputs
of
0.4
to
11
kW.
*If
C6-02
is
set
to
0,
1,
or
F
and
the
initial
value
of
C6-03
and
C6-04
is
2.0
kHz,
the
initial
settings
for
C6-02
are
as
follows:
2:
5.0
kHz,
3:
8.0
kHz,
4:
10
kHz,
5:
12.5
kHz,
and
6:
15
kHz.
If
the
carrier
frequency
is
set
higher
than
the
factory
setting
for
Inverters
with
outputs
of
7.5
kW
or
more,
the
Inverter
rated
current
will
need
to
be
reduced.
Parame-
ter
Num-
ber
Name Unit Factory Setting
- Inverter Capacity kW 18.5 22 30 37 45 55 75 90 110
o2-04 kVA selection - 9 A B C D E F 10 11
b8-03
Energy-saving
filter
time
constant
s0.50
(Open
loop
vector
control) 2.00
(Open
loop
vector
control)
b8-04
Energy-saving
coeffi-
cient
-
57.87 51.79 46.27 38.16 35.78 31.35 23.10 23.10 23.10
C6-02
Carrier
frequency
selec-
tion
*
-664333331
-
Carrier
frequency
selec-
tion
upper
limit
-666444441
E2-01
(E4-01)
Motor
rated
current A
65.8 77.2 105.0 131.0 160.0 190.0 260.0 260.0 260.0
E2-02
(E4-02)
Motor
rated
slip Hz 1.67 1.70 1.80 1.33 1.60 1.43 1.39 1.39 1.39
E2-03
(E4-03)
Motor
no-load
current A 15.7 18.5 21.9 38.2 44.0 45.6 72.0 72.0 72.0
E2-05
(E4-05)
Motor
line-to-line
resis-
tance
Ω
0.101 0.079 0.064 0.039 0.030 0.022 0.023 0.023 0.023
E2-06
(E4-06)
Motor
leak
inductance % 20.1 19.5 20.8 18.8 20.2 20.5 20.0 20.0 20.0
E2-10
Motor
iron
loss
for
torque
compensation
W
505 538 699 823 852 960 1200 1200 1200
L2-02
Momentary
power
loss
ridethru
time
s 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
L2-03
Min.
baseblock
(BB)
time
s 1.0 1.0 1.1 1.1 1.2 1.2 1.3 1.5 1.7
L2-04 Voltage
recovery
time s 0.6 0.6 0.6 0.6 0.6 1.0 1.0 1.0 1.0
L8-02 Overheat
pre-alarm
level °C 100 90 90 95 100 105 95 100 95
