Omron SYSDRIVE 3G3RV Series User Manual

O
ptions and Peripheral Devices
9
-
2
5
Wiring Example
A wiring example for a Simple Input Noise Filter is shown below.
Dimensions
The dimensions of a Simple Input Noise Filter are given below.
Model
3G3EV-
Dimensions
Diagram
Dimensions
Weight
(kg)
W D Hmax A A' B
Mounting
Screws
PLNFD2103DY
1
120 80 55 108 - 68
M4 × 4
20 mm
0.2
PLNFD2153DY 120 80 55 108 - 68
M4 × 4
20 mm
0.2
PLNFD2203DY 170 90 70 158 - 78
M4 × 4
20 mm
0.4
PLNFD2303DY
2
170 110 70 - 79 98
M4 × 6
20 mm
0.5
PLNFD4053DY 170 130 75 - 79 118
M4 × 6
30 mm
0.3
PLNFD4103DY 170 130 95 - 79 118
M4 × 6
30 mm
0.4
PLNFD4153DY 170 130 95 - 79 118
M4 × 6
30 mm
0.4
PLNFD4203DY 200 145 100 - 94 133
M4 × 6
30 mm
0.5
PLNFD4303DY 200 145 100 - 94 133
M4 × 6
30 mm
0.6
R
S
T
R
S
T
U
V
W
E
MCCB
IN
R
S
T
U
V
W
IM
Inverter
Input Noise Filter
Dimensions Diagram 1 Dimensions Diagram 2
