26
n Input Noise Filter
An
Input
Noise
Filter
reduces
noise
coming
into
the
inverter
from
the
power
supply
line
and
to
reduce
noise
flowing
from
the
inverter
into
the
power
supply
line.
Connected
the
Filter
to
the
power
supply
input
side.
Models and Application
The
standard
models
of
Input
Noise
Filters
are
listed
in
the
following
table.
Wiring Example
Wiring
for
an
Input
Noise
Filter
is
the
same
as
that
for
a
Simple
Input
Noise
Filter.
Inverter Input Noise Filter
Voltage
Class
Max. Applicable
Motor Capacity
(kW)
Model No. Qty Rated (A)
200-V
Class
5.5 3G3IV-PFN258L4207 1
42
7.5 3G3IV-PFN258L5507 1
55
11 3G3IV-PFN258L7534 1
75
15 3G3IV-PFN258L10035 1 100
18.5 3G3IV-PFN258L13035 1 130
22 3G3IV-PFN258L13035 1 130
30 3G3IV-PFN258L18007 1 180
37 3G3IV-PFN359P25099 1 250
45 3G3IV-PFN359P25099 1 250
55 3G3IV-PFN359P30099 1 300
75 3G3IV-PFN359P25099 2 500
90 3G3IV-PFN359P25099 2 500
110 3G3IV-PFN359P30099 2 600
400-V
Class
11 3G3IV-PFN258L4207 1
42
15 3G3IV-PFN258L5507 1
55
18.5 3G3IV-PFN258L5507 1
55
22 3G3IV-PFN258L7534 1
75
30 3G3IV-PFN258L10035 1 100
37 3G3IV-PFN258L13035 1 130
45 3G3IV-PFN258L13035 1 130
55 3G3IV-PFN258L18007 1 180
75 3G3IV-PFN359P25099 1 250
90 3G3IV-PFN359P30099 1 300
110 3G3IV-PFN359P30099 1 300
132 3G3IV-PFN359P25099 2 500
160 3G3IV-PFN359P25099 2 500
FN 258L- 100 - 35
LOAD
L1
Õ
L2
Õ
9713
L3
Õ
E
L1
L2
L3
E
LINE
MADE IN SWITZERLAND
E
N13
32
00
S
L11
+
480VAC / 50 - 60Hz
100A@50ßC / - 25ß + 85ßC
