nSetting Parameters
Here, the procedure is shown to change C1-01 (Acceleration Time 1) from 10 s to 20 s.
Table 3.3 Setting Parameters in Advanced Programming Mode
Step
No.
Digital Operator Display Description
1Power supply turned ON.
2MENU Key pressed to enter Drive Mode.
3
MENU Key pressed to enter Quick Program-
ming Mode.
4
MENU Key pressed to Enter Advanced Pro-
gramming Mode.
5 ENTER pressed to access monitor display.
6
Increment or Decrement Key pressed to dis-
play C1-01 (Acceleration Time 1).
7
ENTER Key pressed to access setting display.
The setting of C1-01 (10.00) is displayed.
8
Digit Selection/RESET Key pressed to move
the flashing digit to the right.
9
Increment Key pressed to change set value to
20.00 s.
10
ENTER Key pressed to enter the set data.
“END” is displayed for 10 s and then the
entered value is displayed for 0.5 s.
11 The monitor display for C1-01 returns.
