Omron SYSDRIVE 3G3RV Series User Manual

6
-
28
Fig 6.27 Terminals A1 and A2 Inputs
nAdjusting Frequency Gain Using an Analog Input
When H3-09 is set to 1 (frequency gain), you can adjust the frequency gain using an analog input.
Fig 6.28 Frequency Gain Adjustment (Terminal A2 Input)
The frequency gain for terminal A1 is the sum of H3-02 and terminal A2 gain. For example, when H3-02 is set
to 100% and terminal A2 is set to 5 V, the terminal A1 frequency reference will be 50%.
nAdjusting Frequency Bias Using an Analog Input
When parameter H3-09 is set to 0 (add to terminal A1), the frequency equivalent to the terminal A2 input volt-
age is added to A1 as a bias.
Frequency reference
Terminal A1 input
Terminal A1
input voltage
Frequency reference
Terminal A2 input
Terminal A2 input
voltage (current)
Frequency gain
Multi-function analog input
terminal A2 input level
Frequency reference
H3-02
H3-02
0.5
0 10 V
Terminal A1 input voltage
100%
50%
