O
ptions and Peripheral Devices
9
-
7
* 1. Recommended
Options
can
be
ordered
from
OMRON
using
the
above
model
numbers.
*2.Not
applicable
to
(-E)
models.
Table 9.1 Options and Peripheral Devices
Type Name Model
number Application
Special
Mounted
Options
Fan
Unit 3G3IV-PFAN
@
Replacement
fan
for
Inverters
equipped
with
a
cooling
fan.
Replace
the
Cooling
Fan
when
the
fan
replacement
time
has
come
or
a
cooling
fan
fault
(FAN)
alarm
has
been
displayed.
Separately
Installed
Options
Scaling
Meter K3TJ-V11
@
Connects
to
a
multi-function
analog
output
from
the
Inverter.
Used
to
display
rotational
speeds
of
motors,
line
speeds,
etc.,
in
physical
units.
Analog
Operator
(stan-
dard
with
steel
panels)
3G3IV-PJVOP96
@
Allows
frequency
reference
settings
and
ON/OFF
operation
control
to
be
performed
by
analog
references
from
a
remote
location
(50
m
max.).
Frequency
counter
specifications:
75
Hz,
150
Hz,
220
Hz
Analog
Operator
(small,
plastic)
3G3IV-PJVOP95
@
Allows
frequency
reference
settings
and
ON/OFF
operation
control
to
be
performed
by
analog
references
from
a
remote
location
(50
m
max.).
Frequency
counter
specifications:
60/120
Hz,
90/180Hz
Special
Options
Braking
Unit 3G3IV-PCDBR
@B
Used
with
a
Braking
Resistor
Unit
to
reduce
the
deceleration
time
of
the
motor.
Not
required
with
Inverters
of
7.5
kW
or
less
for
200-V
class
Inverters
or
for
Inverters
of
15
kW
or
less
for
400-V
class
Inverters.
Braking
Resistor
Unit 3G3IV-PLKEB
@
Consumes
the
regenerative
motor
energy
with
a
resistor
to
reduce
deceleration
time
(use
rate:
10%
ED).
Braking
Resistor 3G3IV-PERF150WJ
@01
Consumes
the
regenerative
motor
energy
with
a
resistor
to
reduce
deceleration
time
(use
rate:
3%
ED).
Not
required
with
Inverters
of
3.7
kW
or
less
for
200-V
class
Inverters
or
for
Inverters
of
2.2
kW
or
less
for
400-V
class
Inverters.
DC
Reactor 3G3HV-PUZDAB
@
Used
to
control
harmonics
generated
by
the
Inverter
and
to
improve
the
input
power
fac-
tor
of
the
Inverter.
All
Inverters
of
18.5
kW
or
higher
contain
built-in
DC
reactors.
Digital
Operator
with
LCD
Display
3G3IV-PJVOP160 Displays
messages
on
an
LCD.
Digital
Operator
with
LED
Display
3G3IV-PJVOP161 Display
messages
on
an
LED
display.
Standard
in
Asia
and
Europe.
Digital
Operator
Connec-
tion
Cable
3G3IV-PCN126
(1
m)
Extension
cable
to
use
a
3G3RV-series
Digital
Operator
remotely.
Cable
length:
1
m
or
3
m
3G3IV-PCN326
(3
m)
Option
Cards
Analog
Monitor
Cards*2
3G3IV-PAO08
The
resolution
of
the
analog
output
from
the
Inverter
is
11
bits.
Use
this
Card
if
there
are
not
enough
analog
outputs.
The
output
resolution
of
the
3G3IV-PAO08
is
(0
to
10
V
output
for
frequency
meters
or
output
current
meters)
and
the
output
resolution
of
the
3G3IV-PAO12
is
1/2048
(0
to
10
V
for
control
applications).
3G3IV-PAO12
PG
Speed
Control
Cards
3G3FV-PPGA2
Phase-A
(single-phase)
pulse
input
and
open
collector
output
for
V/f
control
with
a
PG.
Maximum
response
frequency:
30
kHz,
with
pulse
monitor
output.
3G3FV-PPGB2
Phase-A/B
pulse
inputs
and
open
collector
output
for
flux
vector
control.
Maximum
response
frequency:
30
kHz,
with
pulse
monitor
output.
3G3FV-PPGD2
Phase-A
(single-phase)
pulse
input
and
line
driver
output
(RS-422)
for
V/f
control
with
a
PG.
Maximum
response
frequency:
300
kHz,
with
pulse
monitor
output.
3G3FV-PPGX2
Phase-A/B/Z
pulse
inputs
and
line
driver
output
(RS-422)
for
flux
vector
control.
Maximum
response
frequency:
300
kHz,
with
pulse
monitor
output
DeviceNet
Communica-
tions
Card
3G3FV-PDRT1-SIN
Used
for
DeviceNet
communications
with
a
Programmable
Controller
or
other
DeviceNet
master
device.
Recommended
Separately
Installed
Options
*1
AC
Reactor
(Yaskawa) 3G3IV-PUZBAB@
Used
to
control
harmonics
generated
by
the
Inverter
or
when
the
power
supply
capacity
is
greatly
larger
than
the
Inverter’s
capacity.
Also
used
to
increase
the
power
factor.
Simple
Input
Noise
Filter
(Yaskawa)
3G3EV-PLNFD
@
Reduces
noise
coming
into
the
inverter
from
the
power
supply
line
and
to
reduce
noise
flowing
from
the
inverter
into
the
power
supply
line.
Connected
to
the
power
supply
input
side.
Input
Noise
Filter
(Schaffner)
3G3IV-PFN
@
Reduces
noise
coming
into
the
inverter
from
the
power
supply
line
and
to
reduce
noise
flowing
from
the
inverter
into
the
power
supply
line.Connected
to
the
power
supply
input
side.
Input
Noise
Filter
(Schaffner)
for
EMC
Directive
3G3RV-PFSo Required
for
the
3GRV
Inverter
to
meet
the
EMC
Directive.
Output
Noise
Filter
(Tokin)
3G3IV-PLF
@
Controls
noise
generated
by
the
Inverter
so
it
does
not
enter
the
power
supply.
Con-
nected
to
the
motor
output
side.
