Omron SYSDRIVE 3G3RV Series User Manual

A
pplication and Overload Selections
6
-
3
nDifference between CT and VT
The characteristics of CT (low carrier, constant torque) and VT (high carrier, variable torque) are shown
below.
nSetting Precautions
C6-01 (CT/VT Selection)
When setting C6-01, observe the following precautions.
• Depending on the set value in C6-01, the setting range of the related parameters is limited as follows:
* Factory settings depend on Inverter capacity.
200 V and 400 V Class Inverters for 0.4 to 22 kW: 6 (15 kHz)
200 V Class Inverters for 30 to 90 kW, or 400 V Class Inverters for 30 to 185 kW: 4 (10 kHz)
200 V Class Inverter for 110 kW, or 400 V Class Inverters for 220 to 300 kW: 1 (2 kHz)
• When the setting in E1-04 or E3-02 is greater than 150 Hz, if C6-01 is set to 0, an OPE02 (Parameter set-
ting range error) will occur.
CT: Low Carrier, Constant Torque VT: High Carrier, Variable Torque
Constant torque means a fixed load torque for all motor
speed, and it requires overload resistance capability.
Applications include pushers, conveyors, cranes, and
other friction or heavy loads.
Var ia bl e torque means that the load torque will decrease
as the speed decreases. Normally, overload resistance
capability is not required. Applications include fans and
pumps.
Low carrier: Acoustic noise is present. High carrier: Acoustic noise is not present.
C6-01 Set Value 0 (Low Carrier, Constant Torque) 1 (High Carrier, Variable Torque)
Inverter Overload Protection Level
150% Inverter rated current/1
min.
120% Inverter rated current/1
min.
C6-02 (Carrier Frequency Selection)
0: Low carrier, low noise
1: Carrier 2 kHz
0: Low carrier low noise
1: Carrier 2 kHz
2: Carrier 5 kHz
3: Carrier 8.0 kHz
4: Carrier 10.0 kHz
5: Carrier 12.5 kHz
6: Carrier 15 kHz
F: User-set*
E1-04 and E3-02 (Max. Output Fre-
quency)
150 Hz 400 Hz
L3-02 (Stall Prevention Level During
Acceleration)
150% 120%
L3-06 (Stall Prevention Level During
Operation)
150% 120%
0
Constant Torque
Torque
Motor speed
Variable Torque
Torque
Motor speed
