4
-
10
nSetting
the
Control
Method
Any
of
the
following
three
control
methods
can
be
set.
• V/f
control
without
PG
(normal
speed
control)
• V/f
control
with
PG
(simple
speed
feedback
control)
• Open-loop
vector
control
(high-performance
control
without
PG)
V/f
Control
without
PG
(A1-02
=
0)
• Set
either
one
of
the
fixed
patterns
(0
to
E)
in
E1-03
(V/f
Pattern
Selection)
or
set
F
in
E1-03
to
specify
a
user-set
pattern
as
required
for
the
motor
and
load
characteristics
in
E1-04
to
E1-13
in
advanced
program-
ming
mode.
• Perform
stationary
autotuning
for
the
line-to-line
resistance
only
if
the
motor
cable
is
50
m
or
longer
for
the
actual
installation
or
the
load
is
heavy
enough
to
produce
stalling.
Refer
to
the
following
section
on
Autotuning
for
details
on
stationary
autotuning.
V/f
Control
with
PG
(A1-02=1)
• Set
either
one
of
the
fixed
patterns
(0
to
E)
in
E1-03
(V/f
Pattern
Selection)
or
set
F
in
E1-03
to
specify
a
user-set
pattern
as
required
for
the
motor
and
load
characteristics
in
E1-04
to
E1-13
in
advanced
program-
ming
mode.
• Set
the
number
of
motor
poles
in
E2-04
(Number
of
Motor
Poles)
• Set
the
number
of
rotations
per
pulse
in
F1-01
(PG
Constant).
If
there
is
a
reduction
gear
between
the
motor
and
PG,
set
the
reduction
ratio
in
F1-12
and
F1-13
in
advanced
programming
mode.
• Perform
stationary
autotuning
for
the
line-to-line
resistance
only
if
the
motor
cable
is
50
m
or
longer
for
the
actual
installation
or
the
load
is
heavy
enough
to
produce
stalling.
Refer
to
the
following
section
on
Autotuning
for
details
on
stationary
autotuning.
Open-loop
Vector
Control
(A1-02
=
2)
Perform
autotuning.
If
the
motor
can
be
operated
without
a
load,
perform
rotational
autotuning.
If
the
motor
cannot
be
operated,
perform
stationary
autotuning.
Refer
to
the
following
section
on
Autotuning
for
details
on
autotuning.
Simple
operation
of
a
general-purpose
motor
at
50
Hz:
E1-03
=
0
Simple
operation
of
a
general-purpose
motor
at
60
Hz:
E1-03
=
F
(default)
or
1
If
E1-03
=
F,
the
default
setting
in
the
user
setting
from
E1-04
to
E1-13
are
for
60
Hz
(50
Hz
for
-E
models)
Simple
operation
of
a
general-purpose
motor
at
50
Hz:
E1-03
=
0
Simple
operation
of
a
general-purpose
motor
at
60
Hz:
E1-03
=
F
(default)
or
1
If
E1-03
=
F,
the
default
setting
in
the
user
setting
from
E1-04
to
E1-13
are
for
60
Hz
(50
Hz
for
-E
models)
