Omron SYSDRIVE 3G3RV Series User Manual

5
-
14
*The factory setting will change when the control method is changed. (V/f control factory settings are given.)
nTimer Function: b4
Parameters for timer functions are shown in the following table.
*For (-E) models.
b3-03
Speed
search
decelera-
tion time
(current
detection)
Sets the output frequency
deceleration time during speed
search in 1-second units.
Set the time for deceleration
from the maximum output fre-
quency to the minimum out-
put frequency.
0.1 to
10.0
2.0 sNoANoA193H6-53
SpdSrch
Dec Time
b3-05
Speed
search wait
time (cur-
rent detec-
tion or
speed cal-
culation)
Sets the contactor operating
delay time when there is a con-
tactor on the output side of the
Inverter. When a speed search
is performed after recovering
from a momentary power loss,
the search operation is delayed
by the time set here.
0.0 to
20.0
0.2 s No A A A 195H 6-53
Search
Delay
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
V/f
V/f
with
PG
Open
Loop
LCD
Display
b4-01
Timer func-
tion ON-
delay time
Sets the timer function out-
put ON-delay time (dead
band) for the timer function
input, in 1-second units.
Enabled when a timer func-
tion is set in H1-oo or H2-
oo.
0.0 to
300.0
(0.0 to
3000.0)
*
0.0 s No A A A 1A3H 6-116
Delay-ON
Timer
b4-02
Timer func-
tion OFF-
delay time
Sets the timer function out-
put OFF-delay time (dead
band) for the timer function
input, in 1-second units.
Enabled when a timer func-
tion is set in H1-oo or H2-
oo
0.0 to
300.0
(0.0 to
3000.0)
*
0.0 s No A A A 1A4H 6-116
Delay-OFF
Timer
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Regis-
ter
Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
