Omron SYSDRIVE 3G3RV Series User Manual

5
-
60
*The initial value when C6-01 is set to 1 is given. If C6-01 is set to 0, the initial value will be 150%.
L3-04
Stall pre-
vention
selection
during decel
0: Disabled (Deceleration as
set. If deceleration time is
too short, a main circuit
overvoltage may result.)
1: Enabled (Deceleration is
stopped when the main
circuit voltage exceeds
the overvoltage level.
Deceleration restarts
when voltage is returned.)
2: Intelligent deceleration
mode (Deceleration rate
is automatically adjusted
so that in Inverter can
decelerate in the shortest
possible time. Set
deceleration time is
disregarded.)
3: Enabled (with Braking
Resistor Unit)
When a braking option
(Braking Resistor, Braking
Resistor Unit, Braking Unit)
is used, always set to 0 or 3.
0 to 3 1 No Q Q Q 492H
4-8
6-25
StallP Decel
Sel
L3-05
Stall pre-
vention
selection
during run-
ning
0: Disabled (Runs as set.
With a heavy load, the
motor may stall.)
1:Deceleration time 1 (the
deceleration time for the
stall prevention function
is C1-02.)
2:Deceleration time 2 (the
deceleration time for the
stall prevention function
is C1-04.)
0 to 2 1 No A A No 493H 6-42
StallP Run
Sel
L3-06
Stall pre-
vention
level during
running
Effective when L3-05 is 1 or
2.
Set as a percentage of the
Inverter rated current.
Usually setting is not neces-
sary.
The factory setting reduces
the set values when the
motor stalls.
30 to
200
120%
*
No A A No 494H 6-42
StallP Run
Level
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
