Omron SYSDRIVE 3G3RV Series

6
-
26
nSetting Example
An example of stall prevention during deceleration when L3-04 is set to 1 as shown below.
Fig 6.26 Stall Prevention During Deceleration Operation
nSetting Precautions
• The stall prevention level during deceleration differs depending on the Inverter capacity. Refer to the fol-
lowing table for details.
• When using the braking option (braking resistor, Braking Resistor Units, and Braking Units), be sure to set
parameter L3-04 to 0 or 3.
• To decelerate at a shorter time than the deceleration time set when L3-04 is set to 0 with the braking option
enabled, set L3-04 to 3.
Inverter Capacity Stall Prevention Level during Deceleration (V)
200 V class 380
400 V class
E1-01 ≥ 400 V760
E1-01 < 400 V660
Deceleration time controlled to
prevent overvoltage
Deceleration time
(set value)
Time
Output frequency
