I
mproved Operating Efficiency
6
-
3
7
nRelated Parameters
*1.The factory setting will change when the control method is changed. (V/f control factory settings are given.)
*2.The starting torque value can be set only for (-E) models.
nAdjusting Torque Compensation Gain
Normally, there is no need to make this adjustment. Do not adjust the torque compensation gain when using
open loop vector control.
For V/f control, adjust the torque compensation gain in the following circumstances.
• If the cable is very long, increase the set value.
• If the (maximum applicable) motor capacity is smaller than the Inverter capacity, increase the set value.
• If the motor is vibrating, reduce the set value.
Adjust this parameter so that the output current during low-speed rotation does not exceed the Inverter rated
output current range.
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD Display
C4-01
Tor que compensation gain
Set the torque compensation gain using the multi-
plication factor. Normally, there is no need to
change this parameter. Adjust the torque compen-
sation gain in the following circumstances.
•If the cable is very long, increase the set value.
•If the motor is smaller than the maximum
applicable motor of the Inverter, increase the
set value.
•If the motor is vibrating, reduce the set value.
Adjust this parameter so that the output current
during low-speed rotation does not exceed the
Inverter rated output current range.
0.00 to
2.50
1.00 Yes A A A
Tor q Comp Gain
C4-02
Tor que compensation pri-
mary delay time constant
Set the primary delay for the torque compensation
function in ms.
Normally, there is no need to make this setting.
Adjust this parameter in the following circum-
stances.
•If the motor is vibrating, increase the set value.
•If the motor response is low, decrease the set
value.
0 to
10000
200 ms
*1
No A A A
Tor q Comp Time
C4-03
Starting torque value (for-
ward)
Sets the value based on 100% motor’s rated
torque.
0.0 to
200.0
0.0% No No No
A
*2
F TorqCmp@start
C4-04
Starting torque value
(reverse)
Sets the value based on 100% motor’s rated
torque.
-200.0 to
0.0
0.0% No No No
A
*2
R TorqCmp@start
C4-05
Starting torque time con-
stant
Sets the rise time constant (ms) for the starting
torque value.
The filter is disabled if set between 0 and 4 ms.
0 to 200 10 ms No No No
A
*2
Tor qC mp Delay T
