Omron SYSDRIVE 3G3RV Series User Manual

M
achine Protection
6
-
4
1
Fig 6.35 Torque Limit by Analog Input
nSetting Torque Limits Using Parameters and an Analog Input
The following block diagram shows the relationship between torque limit using parameters and torque limit
using an analog input.
The lowest torque limit set from among the following is enabled: Torque limit using parameters, torque limit
using an analog input, 150% of Inverter rating (when set to CT), or 120% of Inverter rating (when set to VT)
set in C6-01.
Fig 6.36 Torque Limit Using Parameters and an Analog Input
Negative
Reverse operation
Regenerative torque limit
Regenerative torque limit
Forward torque limit
Positive/negative torque limits
Positive/negative torque limits
No. of motor rotations
Forward operation
Negative torque limit
Positive
Output torque
Multi-function analog input
Terminal
A2
Forward torque limit
(set value = 10)
Negative torque limit
(set value = 11)
Regenerative torque limit
(set value = 12)
Positive/negative torque limit
(set value = 15)
Positive forward drive
torque
Reverse positive regenerative torque
Forward negative regenerative torque
Reverse
drive
reverse
torque
Min: Minimum value priority circuit
Parame-
Forward torque limit
(L7-01)
Reverse torque limit
(L7-02)
Forward regenerative torque
limit (L7-03)
Reverse regenerative torque
limit (L7-04)
175% of Inverter rated current
Forward torque limit
Reverse torque limit
Forward regenerative
torque limit
Reverse regenerative
torque limit
