nRelated Parameters
Multi-function Digital Outputs (H2-01 to H2-03)
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD Display
L6-01
Tor que detection selection
1
0: Overtorque/undertorque detection disabled.
1: Overtorque detection only with speed agree-
ment; operation continues after overtorque
(warning).
2: Overtorque detected continuously during oper-
ation; operation continues after overtorque
(warning).
3: Overtorque detection only with speed agree-
ment; output stopped upon detection (pro-
tected operation).
4: Overtorque detected continuously during oper-
ation; output stopped upon detection (pro-
tected operation).
5: Undertorque detection only with speed agree-
ment; operation continues after overtorque
(warning).
6: Undertorque detected continuously during
operation; operation continues after over-
torque (warning).
7: Undertorque detection only with speed agree-
ment; output stopped upon detection (pro-
tected operation).
8: Undertorque detected continuously during
operation; output stopped upon detection (pro-
tected operation).
0 to 80 NoAAA
Tor q Det 1 Sel
L6-02
Tor que detection level 1
Open-loop vector control: Motor rated torque is
set as 100%.
V/f control: Inverter rated current is set as 100%.
0 to 300 150% No A A A
Tor q Det 1 Lvl
L6-03
Tor que detection time 1
Set the overtorque/undertorque detection time in
1-second units.
0.0 to
10.0
0.1 sNoAAA
Tor q Det 1 Time
L6-04
Tor que detection selection
2
Output of torque detection 1 is enabled by setting
17 for H2-oo and output of torque detection 1 is
enabled by setting 18 or 18 for H2-oo.
0 to 80 NoAAA
Tor q Det 2 Sel
L6-05
Tor que detection level 2
0 to
300
150% No A A A
Tor q Det 2 Lvl
L6-06
Tor que detection time 2
0.0 to
10.0
0.1 sNoAAA
Tor q Det 2 Time
Set
Value
Function
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
B
Overtorque/undertorque detection 1 NO
(NO contact: Overtorque detection and undertorque detection enabled when contact is ON)
Yes Yes Ye s
17
Overtorque/undertorque detection 1 NC
(NC contact: Overtorque detection and undertorque detection enabled when contact is OFF)
Yes Yes Ye s
18
Overtorque/undertorque detection 2 NO
(NO contact: Overtorque detection and undertorque detection enabled when contact is ON)
Yes Yes Ye s
19
Overtorque/undertorque detection 2 NC
(NC contact: Overtorque detection and undertorque detection enabled when contact is OFF)
Yes Yes Ye s
