Omron SYSDRIVE 3G3RV Series

6
-
84
nData Tables
The data tables are shown below. The types of data are as follows: Reference data, monitor data, and broadcast
data.
Reference Data
The reference data table is shown below. You can both read and write reference data.
INFO
Set the number of data specified using command messages as quantity of specified messages x 2. Handle
response messages in the same way.
Register No. Contents
0000H Reserved
0001H
Frequency reference
Bit 0
Run/stop command 1: Run 0: Stop
Bit 1
Forward/reverse operation 1: Reverse 0: Forward
Bit 2
External error 1: Error (EFO)
Bit 3
Error reset 1: Reset command
Bit 4ComNet
Bit 5ComCtrl
Bit 6 Multi-function input command 3
Bit 7 Multi-function input command 4
Bit 8 Multi-function input command 5
Bit 9 Multi-function input command 6
Bit A Multi-function input command 7
Bits B to FNot used
0002H Frequency reference (Set units using parameter o1-03)
0003H to 0005H Not used
0006H PID target value
0007H Analog output 1 setting (-11 V/-726 to 11 V/726)
0008H Analog output 2 setting (-11 V/-726 to 11 V/726)
0009H
Multi-function contact output setting
Bit 0
Contact output (Terminal M1-M2) 1: ON 0: OFF
Bit 1
PHC1(Contact P1-PC) 1: ON 0: OFF
Bit 2
PHC2(Contact P2-PC) 1: ON 0: OFF
Bits 3 to 5Not used
Bit 6Set error contact (terminal MA-MC) output using bit 7. 1: ON 0: OFF
Bit 7
Error contact (terminal MA-MC) 1: ON 0: OFF
Bits 8 to FNot used
000AH to 000EH Not used
