nSelf-Diagnosis
The
Inverter
has
a
built-in
function
for
self-diagnosing
the
operations
of
serial
communications
interface
cir-
cuits.
This
function
is
called
the
self-diagnosis
function.
The
self-diagnosis
function
connects
the
communica-
tions
parts
of
the
send
and
receive
terminals,
receives
the
data
sent
by
the
Inverter,
and
checks
if
communications
are
being
performed
normally.
Perform
the
self-diagnosis
function
using
the
following
procedure.
1. Turn
ON
the
power
supply
to
the
Inverter,
and
set
67
(communications
test
mode)
in
parameter
H1-05
(Terminal
S7
Function
Selection).
2. Turn
OFF
the
power
supply
to
the
Inverter.
3. Perform
wiring
according
to
the
following
diagram
while
the
power
supply
is
turned
OFF.
4. Turn
ON
the
terminating
resistance.
(Turn
ON
pin
1
on
DIP
switch
1.)
5. Turn
ON
the
power
supply
to
the
Inverter
again.
Fig 6.60 Details of Communications Terminals
Pass
will
be
displayed
on
the
Digital
Operator
if
the
diagnosis
have
finished
correctly.
If
an
error
occurs,
a
CE
(RS-422A/485
communications
error)
alarm
will
be
displayed
on
the
Digital
Operator,
the
error
contact
output
will
be
turned
ON,
and
the
Inverter
operation
ready
signal
will
be
turned
OFF.
