Omron SYSDRIVE 3G3RV Series

C
ommunications Functions
6
-
1
11
Inverter Control Outputs (Register 002C Inverter Status)
The Inverter control outputs for register 002C Inverter status are listed in the following table.
Area Used by Operand of PMCR Instruction
The area used by the operand of the PMCR instruction in the CS-series is shown here.
Word Slave 1 function Word Slave 2 function Word Slave 3 function
01100 During RUN 01200 During RUN 01300 During RUN
01101 Zero speed 01201 Zero speed 01301 Zero speed
01102 Frequency agree 01202 Frequency agree 01302 Frequency agree
01103 Custom speed agree 01203 Custom speed agree 01303 Custom speed agree
01104 Frequency detection 1 01204
Frequency detection 
01304
Frequency detection 
01105
Frequency detection 
01205
Frequency detection 
01305
Frequency detection 
01106 Inverter ready 01206 Inverter ready 01306 Inverter ready
01107 UV 01207 UV 01307 UV
01108 Base block 01208 Base block 01308 Base block
01109 Frequency reference mode 01209 Frequency reference mode 01309 Frequency reference mode
01110 RUN command mode 01210 RUN command mode 01310 RUN command mode
01111 Overtorque detection 01211 Overtorque detection 01311 Overtorque detection
01112 Frequency reference loss 01212 Frequency reference loss 01312 Frequency reference loss
01113 Fault retry 01213 Fault retry 01313 Fault retry
01114 Fault 01214 Fault 01314 Fault
01115 Communications time-over 01215 Communications time-over 01315 Communications time-over
DM
D0100 0111001011100001
Communications
port 7
Communications
port E1
Word
Control Data: C1
DM
Area
Send Data: S
D1000
000B (Number of Send data items:
11) See note 1.)
D1001
0003 (Number of Slaves)
D1002
0001 (Slave 1 address)
D1003
RUN command to Slave 1
D1004
Frequency reference to Slave 1
0002 (Slave 2 address)
RUN command to Slave 2
Frequency reference to Slave 2
0003 (Slave 3 address)
RUN command to Slave 3
Frequency reference to Slave 3
D1005
D1006
D1007
D1008
D1009
D1010
DM Area
Recv Data: D
D2000
0003(Number of Recv data items: 3)
See note 2.)
D2001
Slave 1 Inverter status
D2002
Slave 2 Inverter status
D2003
Slave 3 Inverter status
Note 1. Set the number of Send data items in Hex to the number of words of D1000 through D1010 (11).
Note 2. The number of words of D2001 through D2003 is written in Hex for the number of Recv data
items.
Serial port 2
DM
D0101 0000000000000000
Sequence 000 set
Word
Control Data: C2
