6
-
128
nManual
Motor
Constant
Parameter
Setting
Methods
The
motor
constant
parameters
settings
methods
are
given
below.
Make
(enter)
settings
referring
to
the
motor
test
report.
Motor
Rated
Current
Setting
Set
E2-01
to
the
rated
current
on
the
motor
nameplate.
Motor
Rated
Slip
Setting
Set
E2-02
to
the
motor
rated
slip
calculated
from
the
number
of
rated
rotations
on
the
motor
nameplate.
Amount
of
motor
rated
slip
=
Motor
rated
frequency
(Hz)
-
No.
of
rated
rotations
(r/min)
x
No.
of
motor
poles/
120.
Motor
No-Load
Current
Setting
Set
E2-03
to
the
motor
no-load
current
using
the
rated
voltage
and
rated
frequency.
The
motor
no-load
current
is
not
normally
written
on
the
motor
nameplate.
Consult
the
motor
manufacturer.
Factory
setting
is
the
no-load
current
value
for
a
standard
Yaskawa
4-pole
motor.
Number
of
Motor
Poles
Setting
E2-04
is
displayed
only
when
V/f
control
method
with
PG
is
selected.
Set
the
number
of
motor
poles
(number
of
poles)
as
written
on
the
motor
nameplate.
Motor
Line-to-Line
Resistance
Setting
E2-05
is
set
automatically
when
performing
motor
line-to-line
resistance
autotuning.
When
you
cannot
per-
form
tuning,
consult
the
motor
manufacturer
for
the
line-to-line
resistance
value.
Calculate
the
resistance
from
the
line-to-line
resistance
value
in
the
motor
test
report
using
the
following
formula,
and
then
make
the
setting
accordingly.
• E-type
isolation:
[Line-to
line
resistance
(Ω)
at
75°C
of
test
report]
×
0.92
(Ω)
• B-type
isolation:
[Line-to
line
resistance
(Ω)
at
75°C
of
test
repor]t
×
0.92
(Ω)
• F-type
isolation:
[Line-to
line
resistance
(Ω)
at
115°C
of
test
report]
×
0.87
(Ω)
Motor
Leak
Inductance
Setting
Set
the
amount
of
voltage
drop
due
to
motor
leak
inductance
in
E2-06
using
the
percentage
over
the
motor
rated
voltage.
Make
this
setting
when
the
high-speed
motor
inductance
is
small.
If
the
inductance
is
not
writ-
ten
on
the
motor
nameplate,
consult
the
motor
manufacturer.
Motor
Iron
Saturation
Coefficients
1
and
2
Settings
E2-07
and
E2-08
are
set
automatically
using
autotuning.
Motor
Iron
Loss
for
Torque
Compensation
Setting
E2-10
is
displayed
only
when
in
V/f
control
method.
To
increase
the
torque
compensation
accuracy
when
in
V/f
control
method,
set
the
motor
iron
loss
in
Watts.
