2.2 to 45 kW V/f Pattern
The diagrams show characteristics for a 200-V class motor. For a 400-V class motor, multiply all voltages by
2.
• Constant Torque Characteristics (Set Va lu e: 0 to 3)
• Decrement Torque Characteristics (Set Value: 4 to 7)
• High Startup Torque (Set Value: 8 to b)
• Fixed Output Operation (Set Va l ue : C to E)
Set Valu e 050 Hz Set Valu e 160 Hz Set Val ue 260 Hz Set Va l ue 372 Hz
(Initial value of set value F)
Set Valu e 450 Hz Set Valu e 550 Hz Set Val ue 660 Hz Set Va l ue 760 Hz
Set Valu e 850 Hz Set Valu e 950 Hz Set Val ue A60 Hz Set Valu e B60 Hz
Set Valu e C90 Hz Set Val ue D 120 Hz Set Va l ue E180 Hz
